Jib Cranes & Swing Jib cranes are ideal overhead travelling crane solutions for material handling within a 8m radius and with the rated capacity of 6 tonnes. With pillar-mounted, column mounted, wall-mounted or floor-mounted jib designs, the swing cranes are able to rotate the jib arms with the loads to 180 degree, 270 degree and full 360 degree, which can be a compact and reliable lifting crane solution for various workshops and production lines. Various customized configurations and options are available to improve productivity, reduce labor strains and efforts and ensure higher safety in your application and during operation.

Slewing systems- manual & electric motor driven slewing jib

Swing jib cranes are optional with manual slewing jib & electric motor driven slewing with the slewing degree of 90, 180, 270 ,360 degree according to your requirements.

With motor driven design, the rotation of the slewing jib crane can be controlled by a pendant control with all motion buttons which is hard wired in to the electric hoist/ jib crane with a low voltage to ensure safety, and a remote radio control is also an option which enable the crane operator to operate the crane in a safety distance from the loads and crane.

Floor mounted swing jib & free standing slewing jib crane

The floor mounted or free standing jib crane is a swing crane which can be designed with full rotation of 360 ° with maximum coverage in 360°areas and also can be provided with 180 degree's rotation and 270 degree's rotation.The swing jib arms and loads are supported by the column or pillar which is functioned as a fulcrum, centered by the cantilever to rotate around which has the hoist and loads running along.Under loading, the torque mainly works on the column and cantilever which requires the foundation of the column must be strong enough to support them, therefore customized design is needed. Contact us to get your customized slewing jib crane drawing now. The floor mounted swivel cranes can be your ideal choice for short distance material handling with intense of handling work.

Main parameters of floor mounted slewing jib crane:

Swing crane type: floor mounted jib crane or free standing jib crane

• Lifting capacity of Slewing jib crane：0.5-16 ton
• Cantilever design: full cantilever, drop cantilever, i beam, box girder, enclosed track beam cantilever
• Rotation type of swing jib cantilever: Manual or motor driven
• Degree of slewing jib crane : 180 degree, 270 degree & 360 degree
• Lifting height of Slewing jib crane：3-8m
• Maximum slewing radius of slewing jib crane : 8 m
• Optional jib hoists: electric , manual, chain hoist or wire rope hoist
• Working class of slewing jib crane：A3 A4
• Ambient temperature of slewing jib crane: -20-40℃
• Customized free standing jib crane with specific crane parameters and specifications are available.

Wall mounted jib cranes

Wall mounted jib cranes with slewing jib cranes are an economical overhead travelling crane solutions for light duty loads handling in workshops. The wall mounted slewing jib cranes can be mounted on the walls, columns or other supporting structures existing in the workshop which will save your crane cost and building investment. The wall crane with slewing jib arm does not need to take your floor space or a concrete floor foundation due to the simple structure and light self-weight, which is a good alternative and a economical lifting crane of free standing jib cranes.

Main parameters of wall mounted slewing jib cranes

• Swing crane type: wall mounted jib crane with Slewing jib cranes
• Beam design of the swing crane: H type beam / kbk beam/ enclosed track beam (1-7 meter )
• Slewing degree of swing crane:180 / 270 degree
• Jib hoist design of swing crane: chain jib hoist or wire rope jib hoist
• Load capacity design of swing crane: 1 ton - 5 tons
• lifting height design of swing crane: 3-9 meter
• Mounting type of swing crane: H beam, column beam or wall
• Contact Supplier Get latest price

Portable 360 °Slewing jib crane

The portable Slewing jib crane is a movable jib crane with 360°Slewing jib arms, which has a manual jib hoist or electrical jib hoist with capacity of 0.08 ton, 0.125 ton, 0.25 ton, 0.5 ton and 1 ton, 110 volt single phase or 240-480 volts, 3 phase. For the portable crane design, the portable Slewing jib crane offers a very flexible lifting crane solution for small and light duty material handling , due to the unique jib structure design, safe &reliable operation, time & energy saving , high efficiency and flexibility, cost-effective.

Portable jib crane

Main Parameters of portable jib crane

• Slewing jib crane types: Portable jib cranes on wheels, equipped with manual jib hoist or electric jib hoists
• Rated load of portable Slewing jib crane : 0.08t, 0.125, 0.25t, 0.5t, 1 ton
• Lifting height of portable Slewing jib crane : 1.5m, 2m, 3m
• Turning radius of portable Slewing jib crane : 2m, 3m
• Rotation angle of portable Slewing jib crane : 360°
• Rotary way of portable swing jib crane : electric or manual

Process jib crane design, economical jib crane price

Customized jib cranes with process crane design and particular jib crane specifications for your specific applications are the most cost-effective jib crane solutions.

In order to give your specific quotation quickly, could you please send us the inquiry with the details of the jib crane for us to quote of wall mounted jib crane:

• 1. The type of the jib crane : Free standing jib , Wall mounted jib, or Wall travelling jib?
• 2. Lifting capacity of jib crane: 0.08 ton ,0.25 ton, 0.5 ton, 1 ton, 2 ton, 3 ton , 4 ton, 5 ton , 10 ton , 16 ton?
• 3. Lifting height of jib crane: ____m?
• 4. Valid Radius (the jib length)of jib crane: ____m?
• 5. The Slewing angle of jib crane: Manual or electric Slewing? 180, 270, 360 or other degree?
• Hoisting trolley: Electric or manual? Chain or wire rope hoist?
• 6. The power voltage of jib crane:____?

If you do not know about how to select the jib crane, please feel free to leave us a message or email to us. The reply of our jib crane engineer will be given within 24 hours. Contact us to get the free jib crane design drawing and specific pillar jib crane price .
