Overview of jib cranes pdf download, including types of jib crane pdf, jib crane design pdf, and jib crane specification pdf for you to select the right jib crane for your application.
Overview of slewing jib crane
- Lifting capacity of slewing jib crane：0.5-16 ton
- Cantilever design: full cantilever, drop cantilever, i beam, box girder, enclosed track beam cantilever
- Rotation type of swing jib cantilever: Manual or motor driven
- Degree of slewing jib crane : 180 degree, 270 degree & 360 degree
- Lifting height of slewing jib crane：3-8m
- Maximum slewing radius of Slewing jib crane : 8 m
- Optional jib hoists: electric , manual, chain hoist or wire rope hoist
- Working class of slewing jib jib：A3 A4
- Ambient temperature of slewing jib jib: -20-40℃
Customized free standing jib crane with specific crane parameters and specifications are available.
Main types of jib cranes
- BB Wall-travelling Jib Crane -Lifting capacity: o.5-16t, Lifting height: 6-30m, Working class: A3.
- BX Wall Mounted Jib Crane -Lifting capacity: o.25-1t, Lifting height: 1-10m, Working class: A3.
- Portable jib cranes - 0.08t, 0.125, 0.25t, 0.5t, 1 ton portable jib crane on wheels/ rollers, self-supportive jib mobile crane design, no foundation, wide application. Mobile jib crane & Movable jib crane for sale, economical & profitable.
